MatchFast® A4 stainless heavy section panel fastener, 16mm washer
A4/316 grade stainless steel composite panel fastener for fixing to heavy section steel
Supplied pre-assembled with a 16mm sealing washer, normally used in wall / vertical applications
Estimated lead times
4-6 Days
Estimated lead times
4-6 Days
Estimated lead times
4-6 Days
Estimated lead times
4-6 Days
Estimated lead times
4-6 Days
Estimated lead times
4-6 Days
Estimated lead times
4-6 Days
Estimated lead times
4-6 Days
Estimated lead times
4-6 Days
Estimated lead times
4-6 Days
Product Code
MF15-SSA4-HT-S16-6.3
MF15-SSA4-HT-S16-6.3 x 105
Lead Time
4-6 Days
Lead Time
4-6 Days
Lead Time
4-6 Days
Lead Time
4-6 Days
Lead Time
4-6 Days
Your price
Qty
£0.86
(ex.VAT)
As low as:
(ex.VAT)
As low as:
£85.80
(ex.VAT)
MF15-SSA4-HT-S16-6.3 x 150
MF15-SSA4-HT-S16-6.3 x 250
MF15-SSA4-HT-S16-6.3 x 130
MF15-SSA4-HT-S16-6.3 x 105
MF15-SSA4-HT-S16-6.3 x 200
Key Features
Specification
Capacity
Performance
Installation
Downloads
Description
Stainless steel high thread fastener for fixing composite panel systems to heavy steel.
Features & Benefits
- High thread provides optimal clamping force to top sheet
- Genuine A4 grade stainless steel for optimum corrosion resistance
- Consistently high pull-out and shear values
- Purpose designed for easy and effective installation
- Supplied pre-assembled with a stainless steel / EPDM rubber 16mm diameter sealing washer, normally used in vertical / wall applications
Application
- For mechanically fixing composite panel systems to heavy steel purlins and sections
Fastener Material
Fastener
Austenitic Stainless Steel A4 Grade (316) with organic coating
Sealing Washer
S16 washer
Durability Class
|
Years / Environment
|
|||||||
|---|---|---|---|---|---|---|---|
| Interior | Semi-interior | Rural | Urban | Industrial / Coastal | Marine | Swimming pools & Chemical plants | |
| Corrosivity Category | C1 | - | C2 | C3 | C4 | C5 | - |
| Austenitic Stainless Steel A4 Grade (316) | 40 | 40 | 40 | 40 | 25 | 25 | 0 |
Dimensions
Diameter
6.3 mm
Head Style
Bi-Hex 11mm
Fastener Material
Fastener
Austenitic Stainless Steel A4 Grade (316) with organic coating
Sealing Washer
S16 washer
Durability Class
|
Years / Environment
|
|||||||
|---|---|---|---|---|---|---|---|
| Interior | Semi-interior | Rural | Urban | Industrial / Coastal | Marine | Swimming pools & Chemical plants | |
| Corrosivity Category | C1 | - | C2 | C3 | C4 | C5 | - |
| Austenitic Stainless Steel A4 Grade (316) | 40 | 40 | 40 | 40 | 25 | 25 | 0 |
Dimensions
Diameter
6.3 mm
Length (mm)
150 mm
Effective Thread Length (Min)
56 mm
Effective Thread Length (Max)
112 mm
Head Style
Bi-Hex 11mm
Drilling Capacity
Steel
4 mm
15 mm
Fastener Material
Fastener
Austenitic Stainless Steel A4 Grade (316) with organic coating
Sealing Washer
S16 washer
Durability Class
|
Years / Environment
|
|||||||
|---|---|---|---|---|---|---|---|
| Interior | Semi-interior | Rural | Urban | Industrial / Coastal | Marine | Swimming pools & Chemical plants | |
| Corrosivity Category | C1 | - | C2 | C3 | C4 | C5 | - |
| Austenitic Stainless Steel A4 Grade (316) | 40 | 40 | 40 | 40 | 25 | 25 | 0 |
Dimensions
Diameter
6.3 mm
Length (mm)
250 mm
Effective Thread Length (Min)
142 mm
Effective Thread Length (Max)
211 mm
Head Style
Bi-Hex 11mm
Drilling Capacity
Steel
4 mm
15 mm
Fastener Material
Fastener
Austenitic Stainless Steel A4 Grade (316) with organic coating
Sealing Washer
S16 washer
Durability Class
|
Years / Environment
|
|||||||
|---|---|---|---|---|---|---|---|
| Interior | Semi-interior | Rural | Urban | Industrial / Coastal | Marine | Swimming pools & Chemical plants | |
| Corrosivity Category | C1 | - | C2 | C3 | C4 | C5 | - |
| Austenitic Stainless Steel A4 Grade (316) | 40 | 40 | 40 | 40 | 25 | 25 | 0 |
Dimensions
Diameter
6.3 mm
Length (mm)
130 mm
Effective Thread Length (Min)
36 mm
Effective Thread Length (Max)
92 mm
Head Style
Bi-Hex 11mm
Drilling Capacity
Steel
4 mm
15 mm
Fastener Material
Fastener
Austenitic Stainless Steel A4 Grade (316) with organic coating
Sealing Washer
S16 washer
Durability Class
|
Years / Environment
|
|||||||
|---|---|---|---|---|---|---|---|
| Interior | Semi-interior | Rural | Urban | Industrial / Coastal | Marine | Swimming pools & Chemical plants | |
| Corrosivity Category | C1 | - | C2 | C3 | C4 | C5 | - |
| Austenitic Stainless Steel A4 Grade (316) | 40 | 40 | 40 | 40 | 25 | 25 | 0 |
Dimensions
Diameter
6.3 mm
Length (mm)
105 mm
Effective Thread Length (Min)
31 mm
Effective Thread Length (Max)
67 mm
Head Style
Bi-Hex 11mm
Drilling Capacity
Steel
4 mm
15 mm
Fastener Material
Fastener
Austenitic Stainless Steel A4 Grade (316) with organic coating
Sealing Washer
S16 washer
Durability Class
|
Years / Environment
|
|||||||
|---|---|---|---|---|---|---|---|
| Interior | Semi-interior | Rural | Urban | Industrial / Coastal | Marine | Swimming pools & Chemical plants | |
| Corrosivity Category | C1 | - | C2 | C3 | C4 | C5 | - |
| Austenitic Stainless Steel A4 Grade (316) | 40 | 40 | 40 | 40 | 25 | 25 | 0 |
Dimensions
Diameter
6.3 mm
Length (mm)
200 mm
Effective Thread Length (Min)
91 mm
Effective Thread Length (Max)
161 mm
Head Style
Bi-Hex 11mm
Drilling Capacity
Steel
4 mm
15 mm
Build-up
Effective thread length
Fastener Shear Performance VR,K
|
Substrate
Composite panel
|
4 mm |
| Steel | |
| 0.5 mm | 1.04 kN |
Fastener pull-out performance
| NR,II,K (Tensile - Pull-out) | 4mm Steel: 9.39 kN |
| 8mm Steel: 15.63 kN |
Fastener Pullover Performance NR,K
|
Substrate
Steel
|
S16 washer |
| Composite panel | 4 mm |
| 0.5 mm | 3.28 kN |
Fastener Shear Performance VR,K
|
Substrate
Composite panel
|
4 mm |
| Steel | |
| 0.5 mm | 1.04 kN |
Fastener pull-out performance
| NR,II,K (Tensile - Pull-out) | 4mm Steel: 9.39 kN |
| 8mm Steel: 15.63 kN |
Fastener Pullover Performance NR,K
|
Substrate
Steel
|
S16 washer |
| Composite panel | 4 mm |
| 0.5 mm | 3.28 kN |
Fastener Shear Performance VR,K
|
Substrate
Composite panel
|
4 mm |
| Steel | |
| 0.5 mm | 1.04 kN |
Fastener pull-out performance
| NR,II,K (Tensile - Pull-out) | 4mm Steel: 9.39 kN |
| 8mm Steel: 15.63 kN |
Fastener Pullover Performance NR,K
|
Substrate
Steel
|
S16 washer |
| Composite panel | 4 mm |
| 0.5 mm | 3.28 kN |
Fastener Shear Performance VR,K
|
Substrate
Composite panel
|
4 mm |
| Steel | |
| 0.5 mm | 1.04 kN |
Fastener pull-out performance
| NR,II,K (Tensile - Pull-out) | 4mm Steel: 9.39 kN |
| 8mm Steel: 15.63 kN |
Fastener Pullover Performance NR,K
|
Substrate
Steel
|
S16 washer |
| Composite panel | 4 mm |
| 0.5 mm | 3.28 kN |
Fastener Shear Performance VR,K
|
Substrate
Composite panel
|
4 mm |
| Steel | |
| 0.5 mm | 1.04 kN |
Fastener pull-out performance
| NR,II,K (Tensile - Pull-out) | 4mm Steel: 9.39 kN |
| 8mm Steel: 15.63 kN |
Fastener Pullover Performance NR,K
|
Substrate
Steel
|
S16 washer |
| Composite panel | 4 mm |
| 0.5 mm | 3.28 kN |
Fastener Shear Performance VR,K
|
Substrate
Composite panel
|
4 mm |
| Steel | |
| 0.5 mm | 1.04 kN |
Fastener pull-out performance
| NR,II,K (Tensile - Pull-out) | 4mm Steel: 9.39 kN |
| 8mm Steel: 15.63 kN |
Fastener Pullover Performance NR,K
|
Substrate
Steel
|
S16 washer |
| Composite panel | 4 mm |
| 0.5 mm | 3.28 kN |
Installation and handling
| Installation tool | Variable speed electric screw gun |
| Installation drive | Fixfast Matchfast MF1165 |
| Installation speed | 1500 RPM |
| Correct installation | Fasteners should be driven within three degrees of perpendicular to the surface of the fastened material. Use a depth-setting nosepiece to avoid over-driving, and do not over-tighten. Variants with bonded washers should not have the rubber compressed to less than two-thirds of its uncompressed height. Care should be taken when engaging and disengaging from the fastener head to avoid damage to the protective coating. |
| Handling | Fasteners may have sharp edges, and the use of power tools can be dangerous. Use personal protective equipment. Store fasteners in dry conditions. Inspect each fastener before use and do not use damaged fasteners. |
Downloads
Please see the below files available to download for this product
