HomeRangeSurefast

SureFast®

Tube washer and fastener system for flat roofing

Our SureFast fastening system comprises of a range of specialist tube washers, fasteners, pressure plates and termination bar for mechanically fastening insulation and/or membrane to flat roofs.

What makes up the SureFast range?

SF-T tube washers

Our SureFast tube system has been specifically designed to overcome the cold-bridging effect of mechanical fastenings.

Due to the thermal properties of SureFast tube washers, U-value calculations are greatly simplified - as minimal correction factors or penalties need to be considered, saving time at the design stage, and preventing any increase in material costs incurred by thicker insulation requirements.

  • Tubes to suit both insulation and membrane, providing a complete system

  • Comprehensive size range: available in lengths up to 250mm

  • Manufactured from high-quality polypropylene and able to withstand harsh rooftop environments

  • Up to 40 years warranty available for peace of mind

  • Barbed tube option to achieve high design values - sometimes results in fewer fasteners required

  • Pointed tube aids penetration through membrane and insulation

  • Low profile tube for use with Trocal® or TermBar

  • One tube diameter suits all fastener types 4.8-6.1mm diameter

  • 50mm diameter membrane tube for increased pull-over

  • Prevents the fastener head from damaging the membrane

  • Protects the deck and fastener interface

  • Effectively eliminates unwinding forces

View the range

Fasteners

SF-RS-5.8

Our 5.8mm diameter carbon steel fasteners are suited to fixing insulation and single ply/bituminous membrane to steel and timber decks - in combination with appropriate SureFast components.
With a drillpoint designed for fast, accurate penetration of metal decks up to 2 x 1mm.

View the range
SF-RS-SSA4-4.8

A4/316 grade stainless steel fasteners for enhanced corrosion protection, with a 4.8mm thread diameter, for mechanically fixing single ply and flat roofing systems to aluminium*, steel, and timber decks - alongside relevant components of our SureFast range.
*subject to a pull-out test

View the range
SF-RS-SSA4-6.1

A4/316 grade stainless steel fasteners for fixing insulation and single ply/bituminous membranes to concrete and timber decks, with enhanced corrosion resistance.
These fasteners have an optimised 6.1mm thread diameter for excellent pull-out performance and resistance to unwinding.

View the range
SF-RS-HCR-5.8

High corrosion resistant fasteners for fixing to timber, aluminium and steel decks in corrosive environments - such as swimming pools, tunnels, industrial plants, and marine areas.

View the range

Flat roofing components

Pressure plates

For insulation and membrane attachment in flat roofing applications, we have a variety of sizes and profiles to suit most applications.

Our pressure plates are ETA-approved and CE-marked, with stainless steel options for optimum corrosion resistance.

View the range

Termination bar

Available in 4 different profiles to cover the vast majority of applications, including the termination of membrane at parapet walls or penetrations.

View the range

Peel rivets

Designed for fastening insulation and membrane to thin metal decking materials and difficult substrates, in conjunction with SureFast pressure plates.

View the range

Anchor drive rivets

One-piece anchor for fastening flashings and TermBar to concrete or masonry - eliminating the need for separate fixings and plugs.

View the range

Steel grades

Carbon Steel

Carbon steel is suitable for use in internal or external applications in non-corrosive, non-coastal environments. All our carbon steel fasteners feature a corrosion-resistant organic coating which also provides lubrication for ease of drilling while also preventing damage to the steel.

Stainless Steel A4/316

A4/316 Stainless Steel is a super-austenitic alloy containing high levels of molybdenum, nitrogen and nickel – ensuring it is highly resistant to corrosion, tarnishing and stress

High Corrosion Resistant (HCR) 1.4529 Stainless Steel

Containing a minimum of 6% Molybdenum, these fasteners can be used in corrosive, aggressive environments

Head styles

Bugle

The tapered head style ensures the fastener sits nearly flush once installed – either on top of the substrate, or within a tube washer

Countersunk

Ribbed countersunk heads for an unobtrusive finish – with locking notches to firmly grip membrane once installed (available on our SF-RS-CL-5.2 range)

Code explainer

How do I select the correct tube washer and fastener for my flat roof? View our product selector

Tooling

SureFast drive bar

Drive bars at 750mm long allow the operative to stand whilst installing – with replaceable TX25 & 2PP drive bits, meaning the bar can be reused once the drive bit has worn out. Also available at 300mm long.

View the 300mm SureFast drive bar
STOPP drills

Alongside our standard range of masonry drill bits are our specialist STOPP drills specifically for drilling an exact pilot hole depth. Use in conjunction with our Extender drill bar, for easy installation – allowing the operative to stand during installation.

View the 52mm STOPP drill

Want to find out more about tooling for flat roofing? Learn more

Technical back-up and support

Our technical team can carry out both windload and tapered scheme calculations for your flat roof projects.

Need onsite testing? We can come to you. A free-of-charge service for any new-build concrete deck or any refurbishment project, the visit is followed by a comprehensive report which can be used in a windload calculation.

Learn more
