MatchFast® stainless mainfix timber fastener, 15mm washer
A2/304 grade stainless steel fasteners for fixing into timber. Supplied pre-assembled with an Aluminium / EPDM rubber 15mm diameter sealing washer, normally used in wall applications.
Estimated lead times
4-6 Days
Estimated lead times
4-6 Days
Estimated lead times
4-6 Days
Estimated lead times
4-6 Days
Estimated lead times
4-6 Days
Estimated lead times
4-6 Days
Product Code
MFT-SS-A15-6.0
Lead Time
4-6 Days
Lead Time
4-6 Days
Lead Time
4-6 Days
Your price
Qty
£0.32
(ex.VAT)
As low as:
(ex.VAT)
MFT-SS-A15-6.0 x 50
MFT-SS-A15-6.0 x 40
MFT-SS-A15-6.0 x 75
Create New Favourites List
Key Features
Specification
Capacity
Performance
Installation
Downloads
Description
A2 grade Stainless steel moulded fastener for fixing single skin sheeting to timber.
Can also be used for general purpose applications e.g. fixing aluminium.
Build up figures are shown for installation into 18mm ply.
Features & Benefits
- Genuine A2 grade stainless steel
- Excellent self-tapping performance
- Consistently high pull-out and shear values
- Supplied pre-assembled with an Aluminium / EPDM rubber 19mm diameter sealing washer, normally used in roof applications
Application
- For mechanically fixing components of steel, aluminium and metal framing systems to timber
- For mechanically fixing metal sheeting systems to timber
Fastener Material
Fastener
Austenitic Stainless Steel A2 Grade (304) with organic coating
Sealing Washer
A15 Washer
Durability Class
|
Years / Environment
|
||||||
|---|---|---|---|---|---|---|
| Interior | Rural | Urban | Industrial / Coastal | Marine | Swimming pools & Chemical plants | |
| Corrosivity Category | C1 | C2 | C3 | C4 | C5 | - |
| Austenitic Stainless Steel A2 Grade (304) | 30 | 25 | 25 | 15 | 0 | 0 |
Dimensions
Diameter
6 mm
Head Style
Bi-Hex 11mm
Fastener Material
Fastener
Austenitic Stainless Steel A2 Grade (304) with organic coating
Sealing Washer
A15 Washer
Durability Class
|
Years / Environment
|
||||||
|---|---|---|---|---|---|---|
| Interior | Rural | Urban | Industrial / Coastal | Marine | Swimming pools & Chemical plants | |
| Corrosivity Category | C1 | C2 | C3 | C4 | C5 | - |
| Austenitic Stainless Steel A2 Grade (304) | 30 | 25 | 25 | 15 | 0 | 0 |
Dimensions
Diameter
6 mm
Length (mm)
50 mm
Effective Thread Length (Min)
0 mm
Effective Thread Length (Max)
10 mm
Head Style
Bi-Hex 11mm
Fastener Material
Fastener
Austenitic Stainless Steel A2 Grade (304) with organic coating
Sealing Washer
A15 Washer
Durability Class
|
Years / Environment
|
||||||
|---|---|---|---|---|---|---|
| Interior | Rural | Urban | Industrial / Coastal | Marine | Swimming pools & Chemical plants | |
| Corrosivity Category | C1 | C2 | C3 | C4 | C5 | - |
| Austenitic Stainless Steel A2 Grade (304) | 30 | 25 | 25 | 15 | 0 | 0 |
Dimensions
Diameter
6 mm
Length (mm)
40 mm
Head Style
Bi-Hex 11mm
Fastener Material
Fastener
Austenitic Stainless Steel A2 Grade (304) with organic coating
Sealing Washer
A15 Washer
Durability Class
|
Years / Environment
|
||||||
|---|---|---|---|---|---|---|
| Interior | Rural | Urban | Industrial / Coastal | Marine | Swimming pools & Chemical plants | |
| Corrosivity Category | C1 | C2 | C3 | C4 | C5 | - |
| Austenitic Stainless Steel A2 Grade (304) | 30 | 25 | 25 | 15 | 0 | 0 |
Dimensions
Diameter
6 mm
Length (mm)
75 mm
Effective Thread Length (Min)
25 mm
Effective Thread Length (Max)
35 mm
Head Style
Bi-Hex 11mm
Effective thread length
Fastener pull-out performance
| NR,II,K (Tensile - Pull-out) | Timber 20mm embedment: 1.36 kN |
| Timber 35mm embedment: 2.34 kN | |
| Timber 65mm embedment: 4.36 kN |
Fastener pull-out performance
| NR,II,K (Tensile - Pull-out) | Timber 20mm embedment: 1.36 kN |
| Timber 35mm embedment: 2.34 kN | |
| Timber 65mm embedment: 4.36 kN |
Fastener pull-out performance
| NR,II,K (Tensile - Pull-out) | Timber 20mm embedment: 1.36 kN |
| Timber 35mm embedment: 2.34 kN | |
| Timber 65mm embedment: 4.36 kN |
Fastener pull-out performance
| NR,II,K (Tensile - Pull-out) | Timber 20mm embedment: 1.36 kN |
| Timber 35mm embedment: 2.34 kN | |
| Timber 65mm embedment: 4.36 kN |
Installation and handling
| Installation tool | Variable speed electric screw gun |
| Installation drive | Fixfast Matchfast MF1165 |
| Installation speed | 1500 RPM |
| Correct installation | Fasteners should be driven within three degrees of perpendicular to the surface of the fastened material. Use a depth-setting nosepiece to avoid over-driving, and do not over-tighten. Variants with bonded washers should not have the rubber compressed to less than two-thirds of its uncompressed height. Care should be taken when engaging and disengaging from the fastener head to avoid damage to the protective coating. |
| Handling | Fasteners may have sharp edges, and the use of power tools can be dangerous. Use personal protective equipment. Store fasteners in dry conditions. Inspect each fastener before use and do not use damaged fasteners. |
Downloads
Please see the below files available to download for this product
Key Features
Description
A2 grade Stainless steel moulded fastener for fixing single skin sheeting to timber.
Can also be used for general purpose applications e.g. fixing aluminium.
Build up figures are shown for installation into 18mm ply.
Features & Benefits
- Genuine A2 grade stainless steel
- Excellent self-tapping performance
- Consistently high pull-out and shear values
- Supplied pre-assembled with an Aluminium / EPDM rubber 19mm diameter sealing washer, normally used in roof applications
Application
- For mechanically fixing components of steel, aluminium and metal framing systems to timber
- For mechanically fixing metal sheeting systems to timber
Specification
Fastener Material
Fastener
Austenitic Stainless Steel A2 Grade (304) with organic coating
Sealing Washer
A15 Washer
Durability Class
|
Years / Environment
|
||||||
|---|---|---|---|---|---|---|
| Interior | Rural | Urban | Industrial / Coastal | Marine | Swimming pools & Chemical plants | |
| Corrosivity Category | C1 | C2 | C3 | C4 | C5 | - |
| Austenitic Stainless Steel A2 Grade (304) | 30 | 25 | 25 | 15 | 0 | 0 |
Dimensions
Diameter
6 mm
Head Style
Bi-Hex 11mm
Fastener Material
Fastener
Austenitic Stainless Steel A2 Grade (304) with organic coating
Sealing Washer
A15 Washer
Durability Class
|
Years / Environment
|
||||||
|---|---|---|---|---|---|---|
| Interior | Rural | Urban | Industrial / Coastal | Marine | Swimming pools & Chemical plants | |
| Corrosivity Category | C1 | C2 | C3 | C4 | C5 | - |
| Austenitic Stainless Steel A2 Grade (304) | 30 | 25 | 25 | 15 | 0 | 0 |
Dimensions
Diameter
6 mm
Length (mm)
50 mm
Effective Thread Length (Min)
0 mm
Effective Thread Length (Max)
10 mm
Head Style
Bi-Hex 11mm
Fastener Material
Fastener
Austenitic Stainless Steel A2 Grade (304) with organic coating
Sealing Washer
A15 Washer
Durability Class
|
Years / Environment
|
||||||
|---|---|---|---|---|---|---|
| Interior | Rural | Urban | Industrial / Coastal | Marine | Swimming pools & Chemical plants | |
| Corrosivity Category | C1 | C2 | C3 | C4 | C5 | - |
| Austenitic Stainless Steel A2 Grade (304) | 30 | 25 | 25 | 15 | 0 | 0 |
Dimensions
Diameter
6 mm
Length (mm)
40 mm
Head Style
Bi-Hex 11mm
Fastener Material
Fastener
Austenitic Stainless Steel A2 Grade (304) with organic coating
Sealing Washer
A15 Washer
Durability Class
|
Years / Environment
|
||||||
|---|---|---|---|---|---|---|
| Interior | Rural | Urban | Industrial / Coastal | Marine | Swimming pools & Chemical plants | |
| Corrosivity Category | C1 | C2 | C3 | C4 | C5 | - |
| Austenitic Stainless Steel A2 Grade (304) | 30 | 25 | 25 | 15 | 0 | 0 |
Dimensions
Diameter
6 mm
Length (mm)
75 mm
Effective Thread Length (Min)
25 mm
Effective Thread Length (Max)
35 mm
Head Style
Bi-Hex 11mm
Capacity
Effective thread length
Performance
Fastener pull-out performance
| NR,II,K (Tensile - Pull-out) | Timber 20mm embedment: 1.36 kN |
| Timber 35mm embedment: 2.34 kN | |
| Timber 65mm embedment: 4.36 kN |
Fastener pull-out performance
| NR,II,K (Tensile - Pull-out) | Timber 20mm embedment: 1.36 kN |
| Timber 35mm embedment: 2.34 kN | |
| Timber 65mm embedment: 4.36 kN |
Fastener pull-out performance
| NR,II,K (Tensile - Pull-out) | Timber 20mm embedment: 1.36 kN |
| Timber 35mm embedment: 2.34 kN | |
| Timber 65mm embedment: 4.36 kN |
Fastener pull-out performance
| NR,II,K (Tensile - Pull-out) | Timber 20mm embedment: 1.36 kN |
| Timber 35mm embedment: 2.34 kN | |
| Timber 65mm embedment: 4.36 kN |
Installation
Installation and handling
| Installation tool | Variable speed electric screw gun |
| Installation drive | Fixfast Matchfast MF1165 |
| Installation speed | 1500 RPM |
| Correct installation | Fasteners should be driven within three degrees of perpendicular to the surface of the fastened material. Use a depth-setting nosepiece to avoid over-driving, and do not over-tighten. Variants with bonded washers should not have the rubber compressed to less than two-thirds of its uncompressed height. Care should be taken when engaging and disengaging from the fastener head to avoid damage to the protective coating. |
| Handling | Fasteners may have sharp edges, and the use of power tools can be dangerous. Use personal protective equipment. Store fasteners in dry conditions. Inspect each fastener before use and do not use damaged fasteners. |
Downloads
Downloads
Please see the below files available to download for this product
